GRAPHTEC INSTRUMENTS' DISCOVERY NEWSLETTER



AUTOMATING YOUR TRIGGER - ON/OFF

Newsletter No.6, January 12, 2017



Dataloggers for electrical and industrial purposes revolve around three major objectives: recording, monitoring, and testing.

To automate the recording process, the triggering feature is used in setting up conditions. Graphtec’s robust, independent start and stop triggering capability allows users to capture only the data of interest via event-based triggers or time-based triggers.

In this newsletter, we focus on the triggering feature for all Graphtec portable dataloggers-including the external triggering mechanism in automated testing, monitoring and recording processes.


In various datalogging testing scenarios, the ability to process the data files by utilizing the trigger will simplify the testing process. It eliminates down-time and automates the starts and stops for the datalogging application. For example, recording temperature data for heat treatment in an oven chamber can be initiated when a specified temperature is met per user’s specification. Graphtec dataloggers provide several options for this triggering mechanism. They include threshold level, alarm, external input, date, weekly, and time stamp triggering variables.

All triggering features are available on the GL APS software for Graphtec portable dataloggers. In addition, the scheduling feature will appropriate customized test workload to individual test files in advance. Users will be able to set test plans beforehand and customize tests based on each user’s requirements.



KEY VALUES

GL Series Dataloggers Triggering Features

  • Automating your test recording setup
  • Setting threshold levels to initiate and stop recordings
  • Using process automation switches to automate start and stop
  • Software scheduling feature
GRAPHTEC DATA LOGGER - TEMPERATURE MAPPING APPLICATION FOR ENVIRONMENTAL CHAMBERS, SET TRIGGER CONDITIONS FOR EACH CHANNEL HIGH LOW
GRAPHTEC DATA LOGGER - NEW AUTOMATIC SCHEDULER FEATURE ON APS, SET TRIGGERING SCHEDULE FOR START AND STOP SOUCE

Additionally, the trigger can utilize start and stop sources based on the alarm threshold. Conditions can be applied to each of the input channels to set hourly or daily recordings to best suit the file management structure—suited for each user. Repeat function on the triggering setting will then convert the “Time” (or timer) feature into consistent repeatable test files. At the same time, the file is populated on the internal RAM drive or the external SD card. Wireless recording is also available on the GL100, GL240, and GL840s.



EXTERNAL TRIGGERING


In some cases, Graphtec’s recording start and stop sources can be switched on and off using an external triggering feature using a power source from the switch button or power supply of your test fixture. For example: testing battery durability of the loads and temperature levels of the cells can be set to start and stop using the power switches of the battery. This step eliminates the need to switch on a datalogger to start recording—thus providing test engineers an automated datalogging options, eliminating this common human-error associated with test and measurement.

To utilize this feature, you will need the addition of the B-513 Logic/Pulse cable. Within one of the bare terminal leads, the external triggering cable with the ground connected to the ground wire at 0 to +24V single-ended input will directly feed signal to the datalogger for the external triggering feature. Graphte’sc B-513 cable is available through our authorized instruments distributor

SET TRIGGER CONDITIONS FOR EACH CHANNEL: HI, LOW, WIN IN, WIN OUT

SET TRIGGER CONDITIONS FOR EACH CHANNEL: HI, LOW, WIN IN, WIN OUT

NEW AUTOMATIC SCHEDULER FEATURE ON APS

NEW AUTOMATIC SCHEDULER FEATURE ON APS

GRAPHTEC DATA LOGGER - GL840-M, GL840-WV

SCHEDULING FEATURE USING

GRAPHTEC'S APS SOFTWARE



All triggering features are available on the GL APS software for Graphtec portable dataloggers. In addition, the scheduling feature will appropriate customized test workload to individual test files in advance. Users will be able to set test plans beforehand and customize tests based on each user’s requirements.

KEY FEATURES

VARIOUS TRIGGERING METHOD TO CONTROL TEST START AND STOP

GL portable dataloggers provide six different sources for starting and stopping the recording using the trigger functions. Level, Alarm, External Input, Date, Weekly and Time.

EXTERNAL TRIGGERING MECHANISM TO AUTOMATE TESTING

Utilize your power switches for your test fixture and automate the datalogging by using the external triggering mechanism.

 NEW SCHEDULE FEATURE AVAILABLE THROUGH APS SOFTWARE

Scheduling feature on the APS software provides in-depth organization of the test scenarios and scheduling for constant use of the datalogger in the field.



    GRAPHTEC DATA LOGGER - DIGITAL INPUT AND OUTPUT EXTERNAL SAMPLING INPUT SPECIFICATIONS


    GRAPHTEC DATA LOGGER PLATFORM MODEL GL7000
    GRAPHTEC MODULES ARE ATTACHED ONE BY ONE OPTIONAL TOUCH PANEL DISPLAY AVAILABLE
    GRAPHTEC DATA LOGGER TEMPERATURE VDC VAC VDC RMS AC RMS PULSE LOGIC CHARGE ACCEL FREQUENCY STRAIN HIGH SPEED VOLTAGE HIGH VOLTAGE

    DATA PLATFORM - MODEL GL7000

    Discovery Newsletter No. 5, September 15, 2016



    Data acquisition has long been in the forefront of product development and research for discovering new ways to tackle materials and component issues, heat treatment, and life-cycle stress testing.

    Graphtec launched its GL7000 data acquisition platform in 2015 to augment users looking to find a turn-key data acquisition kit that allows recordings of accelerometers, strain gauges, and fast sampling electrical signals (AC and frequency signals) as well as temperature recording for development necessities.


    Next generation Data Acquisition platform GL7000 is a modular type system with selective input amplifiers customized to meet your demands – based on your applications. Engineers may cater their applications to the most cost-effective module set up – adding value and efficiency by increasing the modules to meet new testing scenarios.  The standalone structure with an optional touch panel display provides an easy-to-use turnkey solution that focuses on delivering the necessary data to your hands and eyes as quickly as possible.



    GL7000 achieves a module set up where each amplifier may be added on to the side of the main module unit and is expandable up to 10 modules per main unit.





    MONITORING SENSORS WITH ENGINEERING SCALING

    Discovery Newsletter No.4 | July 26, 2016



    Graphtec dataloggers have long been regarded as the go-to multichannel, portable datalogger for 10 channel and above applications for recording temperature and voltages signals. In this issue of our discovery newsletters, we explore the engineering scaling feature more in depth as we cover the details on how signals from pressure transducers, flow meters, LVDT displacement sensors and various other signals are used in conjunction with the Graphtec GL series.

    Also, discover how additional testing can be made with various physical parameters like distance, pressure, flow, and speed.

    SPEED, FLOW LEVELS, AND TOTALIZATION

    Tachometer and flow sensors that provide pulse signals for rate and speed of flow can be measured and scaled using the GL series line-up with B-513 logic/pulse cable. Four channels are available for pulse signals in this configuration. “Engineering Unit Setting” is also available for all four channels. When monitoring speed rates from a tachometer or an IR speed sensor, pulse signals can be scaled from the measurement value of sensors available in each rotation to an RPM as shown below.

    For flow signals, the individual pulse signal can be converted to the equivalent flow rate as shown above.

    Totalization of flow rates are provided in total gallon in terms of volume. This can be calculated using the “Instantaneous Count” feature where every pulse signal per sampling rate is chosen (ie. 10 pulse signal per 1 minute interval) and will give you the total volume received under the particular sampling interval (in this case a one minute interval).

    Please consult the Graphtec Technical Sales and Support teams at inst.support@graphtecamerica.com & at inst.sales@graphtecamerica.com to discuss your specific applications.



    KEY FEATURES



    RECORD ORIGINAL UNIT OF MEASUREMENT WITH EU

    Ability to record signals for temperature, voltage, pressure, length, displacement, flow, and many other variables available through sensors that output direct proportionate linear and analog VDC signals.

     TOTALIZATION OF FLOW VOLUME

    Works with your flow signal both in terms of rate and volume, and records all data in real time.

     4-20MA CURRENT LOOP SIGNAL RECORDING

    By using model B-551 250 ohm shunt resistor, you are able to record any 4 to 20mA current loops available in most industrial testing solutions.

    GRAPHTEC DATA LOGGER GL240 WITH FLOW SIGNAL MEASUREMENT
    GRAPHTEC DATA LOGGER MIDI LOGGER GL240

    Multiple sensor manufacturers in the industrial, research and development fields provide output signals that are scaled in voltage DC signals or 4 to 20mA current loops. Graphtec dataloggers are able to scale these signals to its original unit of measurement and record data in their respective scales such as pressure (PSI), length (feet), area, frequency (RPM), energy (W) and flow (gal/s).

    The Engineering Unit (EU) setting available on the GL240, GL840s, GL900, and the GL7000 are a direct ratio mapping feature where you set the minimum and the maximum input values from the input signal, and output the EU values in terms of the unit of measurement proportional to that range.



    GRAPHTEC GL100-WL GL100-N

    GL100-WL (WIRELESS) AND GL100-N (NON-WIRELESS)

    COMPACT DATA LOGGERS

    Discovery Newsletter No.3 | May 26, 2016



    In early 2015, Graphtec announced its entry into the compact datalogger market with the GL100 series.

    GL100 comes wireless and non-wireless, handheld with the ability to monitor and record information for temperature (thermocouple and thermistor), humidity, light, UV, CO2, AC (50, 100, 200A), and vibration.

    With the ability to send alarm and emails with triggering capability, you can discover new ways to tackle your datalogging requirement.


    The handheld-type compact GL100 is a datalogger created to handle the wider range of simple datalogging for logistics, transportation, medical, agricultural, and retail outlet purposes. As wireless connections become more frequent and handheld-size datalogging becomes more prevalent, Graphtec built a more intuitive and simple recorder—bringing data to the palm of your hands as quickly and simply as possible.

    Its compact main body carries a microSD memory card slot, and the wireless model (WL) main body will allow access from smart-enabled devices like smart pads and smartphones through the Graphtec app available on iOS and Android OS platforms (available on iTunes App Store and Android apps on Google Play).

    MicroUSB access to PC software for real-time recording is also offered through the GL100APS software.




    GRAPHTEC DATA LOGGER GL840-WV, GL840-M
    GRAPHTEC DATA LOGGER MULTI CHANNEL INCLUDES VOLTAGE PULSE PRESSURE VACUUM SPEED FLOW FREQUENCY TEMPERATURE HUMIDITY

    GL840-M/WV MULTI-CHANNEL DATA LOGGERS

    Discovery Newsletter No.2 | April 26, 2016



    This month, we cover the basic features of the GL840-M multi-input and the GL840-WV withstand-voltage model dataloggers. With these two new models, focus is on the general 20-channel temperature/voltage input datalogger and the voltage-withstand datalogger with higher accuracy, higher voltage input capability and glitch protection. GL840-M is ideal for multichannel measurements of linear voltage output (or 4-20mA current loops), thermocouples, and RTDs. GL840-WV will support requirements for high precision measurement of temperature and voltage as well as high voltage—such as battery cell voltage monitoring and measurement.

    Expandability up to 200 channels

    The key capability of the GL840 is on its expandability of up to 200-channel input measurements using its expansion terminal blocks. The basic configuration for the expansion kit will require an extension cable, extension terminal base, and the 20-channel extension terminal block. The GL840 series, on both the multi-input model and the withstand model, now provides the ability to connect each terminal base in combination with the terminal block—with the extension cable in addition to the traditional method of daisy chaining terminal blocks to each other.





    INTRODUCING WIRELESS ENABLED HANDHELD DATA LOGGERS GL240, GL840-M, AND GL840-WV

    Discovery Newsletter No.1 | March 15, 2016

    Graphtec is excited to bring you the latest generation of our standalone datalogger series – GL240, GL840-M and GL840-WV – with the ability to add secured wireless networks and sensors for AC, vibration, CO2, light and UV measurement. Combining our expertise in sensing and wireless technologies, third generation multichannel dataloggers will provide data access from secured smart devices and wireless PCs in addition to the traditional standalone instrument that has been the industry leader in display-based data acquisition systems.

    BUILDING A GLOBAL STANDARD FOR MULTICHANNEL DATA LOGGING

    Graphtec’s GL series portable instruments offer isolated voltage inputs with high quality measurement per channel that bring accurate measurement of multiple types of data. The new B-568 wireless module add-on will also allow users to connect, operate, and acquire data remotely on the wireless LAN on top of the USB and LAN connection that is currently offered (LAN only available on the GL840 series).


    Q: What are the types of wireless connections available on the new series?

    B-568 wireless option enables a 801.11(b/g/n) WLAN setting where a terminal (or node) connection to a wireless network or a “hot spot” access point connection is made possible. As an “access point” instrument, GL series will allow remote smart devices and wireless PC to access into the GL instruments by using the proprietary hot spot access with the user-defined network. AndroidOS and iOS platforms have a free downloads on their app stores, and the web server interface will allow real-time wireless data access from your PCs web browser.

    Q: What about the security? Does it offer password enabled configuration?

    All wireless configurations come with the ability to set up your WEP or WPA/WPA-2PSK password security on your instruments. Additionally, your firewall can be configured within the network to protect your data. Please consult your IT professional on how to better secure your network.
