GRAPHTEC LAUNCHES GL2000 midi LOGGER HV CAT III - RATED HIGH VOLTAGE HIGH SPEED GENERAL PURPOSE DATALOGGER

Feb 14, 2017

Graphtec America, Inc., a wholly-owned subsidiary of the Graphtec Corporation, is excited to announce the launch of the new high voltage datalogger – GL2000 > Click to learn more. Purposed for line voltage monitoring and dynamic high speed measurement applications for industrial, transportation, and manufacturing facilities, GL2000 offers a maximum input voltage rating of Category III-rated 600V True-RMS measurement in monitoring electrical signals connected to most distribution panels, circuit breakers, and heavy equipment in industrial and manufacturing facilities.

GL2000 midi LOGGER HV complies with EN61010-1:2010 3rd standard adhering to the Category III 600V working voltage (DC or AC-rms to ground) with peak transient voltage of 6000V. The unit has a withstand voltage of AC/DC 5400V for maximum 1 minute between channel-to-GND and channel-to-channel.

Measurement Category EN1010-1:2010 Defined Working Voltage (DC or AC-rms to ground) Peak Transient Voltage Test Source
CAT I 600V 2500V 30 ohm source
CAT I 1000V 4000V 30 ohm source
CAT II 600V 4000V 12 ohm source
CAT II 1000V 6000V 12 ohm source
CAT III 600V 6000V 2 ohm source
CAT III 1000V 8000V 2 ohm source

 “Having four insulated BNC inputs with high voltage capability with real time monitoring and data collection allows you to measure performances of your heavy equipment when utility power or noise cause disruption in the facility.  Having additional monitoring parameters like temperature, humidity, and scaled voltages from proprietary sensor inputs allow a wide variety of usages from this one instruments that can do so much at a very affordable price” says Ken T. Matsunaga, Senior Sales Manager for Graphtec America, Inc.

At 1MS/sec (or 1μs) maximum sampling interval for simultaneous sampling on all four channels, GL2000 also functions as a portable high-speed data acquisition system with standalone and PC-connected real time measurement capability. This allows measurement of unique testing criteria for those problems and troubleshooting in research and development phases that require fine tuning of AC or DC-driven motor systems. Along with monitoring temperature, pressure, flow, and various other sensor signals, GL2000 carry pre-trigger recording feature for monitoring transient data and certain anomalies caused by anomalies in the sensor data.

Measurement Display Range Voltage (DC) 20, 50, 100, 200, 500 mV, 1, 2, 5, 10, 20, 50, 100, 200, 500 1000 V; and 1-5V F.S. * Max. rated safety voltage: ± 600 V DC
DC-RMS (DC Coupling and rms value meas.)

10, 25, 50, 100, 250, 500 mV rms, 1, 2, 5, 10, 25, 50, 100, 250, 500, 1000 V rms F.S. * Max. rated safety voltage: 600 V rms

• Crest Factor: in 1000 V range, up to 1.4 (peak: max. 850V), in other range, up to 2

• Frequency response: 20 Hz to 10 kHz

• Measures the accumulated value of the DC and AC components in effective value in true-RMS range.

Temperature Thermocouple: K, J, E, T, R, S, B, N, W (WRe5-26)
Humidity 0 to 100 % RH - using the humidity sensor (option B-530)
Filter (Low Pass) Off, Line (1.5 Hz), 5, 50, 500 Hz, 5, 50 kHz (at -3dB, -6dB/oct)
A/D Converter 16-bit (effective resolution: 1/40000 of the full range measurement)

GL2000 is now available for sales through authorized manufacturer’s representatives in various regions and your direct Graphtec sales staff at inst.sales@graphtecamerica.com.

Feb. 14 Press Release in pdf (269 KB)   >>  Download Now




GRAPHTEC AMERICA LAUNCHES NEWLY BUILT GL980 HIGH SPEED HIGHT VOLTAGE DATALOGGER

Nov, 2017

Graphtec midi Logger GL980.jpg

Graphtec America is proud to announce the new high speed, high voltage GL980 datalogger > Click to learn more.  The 8ch GL980 offers isolated, analog inputs that are individually configurable for 500VDC, 250 Vrms, or temperature inputs. Simultaneous sampling speeds of 1MS/sec across all 8 channels are achieved with 4 digital inputs to 100kHz, 4GB on board memory with USB and SD memory card support built in. With robust triggering, alarms, EU scaling all in a portable package that can run on standalone batteries with a 7” color display or with host PC, the GL980 is built to provide you versatility for numerous applications.




GLET BOX INTERCONNECT ENCLOSURES FOR GRAPHTEC DATALOGGERS GL240 / GL840 SERIES

July, 2017

GRAPHTEC GL240 GL840 Product Brief Newsletter Press Release


KEY FEATURES FOR GLET BOXES

᛫ Quick Plug System for: 4-20mA Application, Logic/Pulse Input, 0-10VDC Sensor Application, Strain Gauge Measurement
᛫ Offers GLET Box Solution for GL900 High-Voltage, High-Speed Data Loggers with BNC Connection.

Graphtec is now partnering with Althen Sensors & Control Corporation to offer easy plug-in capability for 4-20mA current loop, logic and pulse signals, and strain gauge bridge amplifiers on all GL portable datalogger series. Sampling speed is variant upon the speed of the main unit GL instrument.


For applications monitoring 4-20mA inputs, GLET-IU-BA2-BA4 adapter connectors with up to 4 channel inputs offer a quick plug-and-play scenario where 4-20mA process signals can now be measured and monitored using the GL240 and GL840 datalogging system. The banana plug-in capability is also available on GL900 high speed datalogger.


Logic and pulse inputs can also be measured using a quick plug-in system using the GLET-B513-KA-BA4 (-REL) as an active or passive module enclosure. Active version will offer supply voltage for alarm mechanism for up to 24VDC to power LED alarms and buzzers.


Analog sensors requiring power supplies can now be powered using the GLET-SU2K-BA2/B-514-BI5 using standard power supply to the GL dataloggers. Standard excitation of up to 18VDC/50mA can be supplied to various transducers and sensors.


GLET-SG2K-BA2-BI7 offers excitation bridge amplifier for load cells and strain gauges with up to 3mV/V sensitivity with 5VDC/15mA per channel excitation for max 2 channel measurement. Sampling speed will be limited to the speed of the GL240/ GL840 main unit instrument.

All GLET boxes will require 5-6 week lead time and custom build.



Contact inst.sales@graphtecamerica.com for more information or you can find us at:

http://www.graphtecamerica.com/instruments

July 2017 Press Release in pdf  (338 KB)  >> Download Now




GRAPHTEC LAUNCHES NEW SOLUTIONS ALONG WITH A NEWLY DEVELOPED CONTENT DRIVEN WEBSITE

July 21, 2017

Graphtec America, Inc., a wholly-owned subsidiary of Graphtec Corporation, is proud to announce the launch of a new website (www.graphtecamerica.com/instrument) along with the launch of the GL7000 modular data acquisition platform and GLET box modular adaptors for the GL series portable instruments.*   Data Acquisition and Test Instruments can oftentimes add heavy loads to R&D and engineering cost due to their sophisticated software mechanisms as well as their hardware integration. Graphtec recognizes the engineers’ need for having a flexible and versatile system that meets the demand of the every-day testing as they go from one test site to another. Graphtec dataloggers and data platform eliminate these problems with a system that launches test applications quickly and cost-effectively.

GL7000 with modular style add-on amplifier was originally launched in 2016, and has been providing a versatile and flexible solution for the test instrumentation market.  With this set up, users can eliminate purchases of unnecessary amplifiers by focusing only on channel requirements that meet their basic test scenario.

“This way, cost can be significantly controlled as you work with your basic testing requirement and add on any amplifiers at a later time when scenarios change” says Ken T. Matsunaga, Senior Sales Manager for Graphtec Instruments Division. “ Portability and versatility are the key aspect of our company.  From field on-site testing to maintenance and service requirements, having a recording instrument at a palm of your hand becomes a vital aspect of monitoring and data logging. Eliminating the need for a PC software takes you away from the time it takes to download, measure, and analyze data. Graphtec can offer all of this as a one-stop solution for your testing requirement.”

New website will offer two new solutions for the GL portable series instruments – handy GLET Box Adaptors and Remote Monitoring Solution using Cellular Gateway System.  GLET boxes provide power supply solution using the power plug from the GL240/GL840s to excite power (max 18VDC/50mA) for proprietary transducers and sensors connected to the GL instruments.  They will also offer strain gauge solution for full bridge sensors above 300ohms (0-10V/±10V output) at max 2, 5, and 10mV/V resolution.  Quick connect adaptors for the logic/pulse signal will also be available through the GLET boxes. Remote monitoring solution for the cellular gateway system will be offered in conjunction with Sierra Wireless Airlink® RV50 and GX450** cellular routers. For those interested in monitoring temperature, humidity, pressure, flow, or speed data utilizing GL instruments’ networking capability, this remote monitoring solution will offer a secured remote connection to your dataloggers using proprietary cellular connection.  “The solution has already been launched to several utility and energy companies, and we are excited to announce this to the rest of the world.”



Contact inst.sales@graphtecamerica.com for more information or you can find us at:

http://www.graphtecamerica.com/instruments.

July 2017 Press Release in pdf  (251 KB)  >> Download Now


* GLET boxes are products offered from Althen GmbH Mess- and Sensortechnik.  **RV50 and GX450 is registered trademark from Sierra Wireless, Inc.
